# Irradiance Map in V-Ray 1.5

Nov 9, 2020 Update

## Introduction

Hello everyone! We continue to setup a global illumination in V-Ray. In a previous tutorial on general GI settings and the principles of indirect Illumination, we learned what global Illumination is and why it is needed for photorealistic visualization. In this tutorial, we will consider the exact parameters and arguments for and against an `Brute force GI` vs `Irradiance Map` as the `Primary bounces` `GI engine`.

## Exact Brute force GI

Brute force GI is a basic algorithm that establishes a fixed number of rays reflected from a point in the scene after hitting it by original ray of light. If you remember, it was previously considered that the light ray from the light source falls on the surface of the scene object and is divided into a number of other rays, which in turn, bombard other objects of the scene (remember the example of the dandelion). Of course, the more diffusely reflected rays of the indirect light will the direct light ray be divided into, the more detail and less noise will be on the final image.

`Subdivs` is a parameter trivially influencing the number of reflected rays, to which every original light ray splits, when it reflects from the object of a scene. Numeric value `Subdivs` it is not the actual number of such secondary rays. The actual number of rays will be equal to the square of that number. That is, if `Subdivs` is 2, then this means that the original light ray will be divided into four rays after reflection; if it is equal to 4, the original ray will be split into sixteen secondary and so on.

`Secondary bounces` is the value that specifies how many times will the secondary rays interreflect further. It is active only if the Brute force algorithm is set as an algorithm for rendering `Secondary bounces` in the corresponding dropdown list, because in this case, it will calculate the right amount of interreflections. If the Brute force is set as a `Primary bounces` `GI engine`, the `Secondary bounces` parameter will be inactive.

Brute force algorithm is not adaptive, and simply calculates the GI for each pixel of the final image of the scene, not depending on its complexity, color and detail of objects. Thus, it spends the same amount of computing resources, both in clearly visible and in the unimportant parts of the scene. No wonder why it was named brute force :) We would also like to note that the `Brute force GI` is a direct calculation by the method of Quasi-Monte Carlo (QMC) and that is how it was called in earlier versions of V-Ray, which sometimes caused confusion when 3d artists have been long looking for a Quasi-Monte Carlo GI in the new interface.

The brute force of this algorithm is very irrational; its use leads to monstrous times for calculation, even on simple scenes at an adequate level of quality. Therefore, it is not worth to nominally use it in universal V-Ray settings as the render engine for primary or secondary bounces. Its use is justified only in special situations where other algorithms, because of their adaptability cannot cope with the calculation of small details in the scene, but more on that later.

`Irradiance map` is an adaptive algorithm of rendering global illumination bounces. The main feature of its work is to identify the most important areas of the rendered scene, calculate GI there and fill the GI information about the omitted areas by interpolating the information from the already computed ones.

In order to understand how it works and what the algorithm of `Irradiance map` is, let us look at map generated by it, which, by the way, called the same ­­– irradiance map.

In front of you is the test scene, which was used in the previous tutorial about the GI, with the same geometry and the same direct lighting as before. For clarity, were removed all textures from the scene materials, to not to obstruct the observation of the irradiance map. Look closely at the most crowded with white dots areas. This is the interior angles of the room, rounded ChamferBox angles, and places of close to each other parts of different objects, in particular on the side of the Sphere facing the cube, as well as the contact area of a cube with the front wall. These zones have the greatest importance in obtaining beautiful detailed global illumination.

It is set of these points is the irradiance map, which we see on the image. These points contain information about the color and brightness of GI in those exact areas. The rest of the image is filled with gray color. Gray areas on the irradiance map is part of the scene where irradiance map contains no information about GI. However, it is fully compensated by interpolation between the already computed points of irradiance map. In other words, `Irradiance map` calculates the most important areas only. After this, the missing information on areas, which were not computed, it simply compensated by interpolation, taking information about the color and brightness from the already existing ones.

It is quite obvious that the `Irradiance map` is an adaptive one. In contrast to the `Brute force` (BF), `Irradiance map` (IM) does not calculate samples for each pixel of a scene. It calculates samples for only important areas. Because of this, a very significant saving of computing resources is possible.

`Irradiance map` algorithm builds a three-dimensional map of points, containing information about the GI just on the surface of objects in the scene. In the volumetric view, the irradiance map of our example scene looks as follows:

If we look at shown above second and third screenshots from special utility called Irradiance Map Viewer, we can clearly see not only the fact of three-dimensionality of irradiance map, but also its dependence on the view of camera, through which the rendering of the scene is performed. In particular, immediately striking eye the lack of points on the GI on not visible in the camera frame parts of the cube and on the other side of the room, which is located behind camera.

In IM, the "probing" of important places in the scene in which the GI calculation is performed is implemented very elegantly. It uses the concept of undersampling, previously described in the first tutorial of this series. At first, GI samples cloud is calculated on lowest resolution for all scene details, which is usually less than the rendering resolution. This calculation is just not adaptive, as calculation with BF algorithm. After that, from the obtained data, the most important areas are determined, that is evaluating the very same areas where the more accurate rendering should be performed. Then the next higher resolution rendering takes place, but only in the required areas. This procedure is repeated several times step by step, each time increasing the resolution, and so, until it reaches the maximum specified resolution of the IM. The minimum and maximum resolution of IM rendering are set in its parameters. The step of calculations differs in twice more or twice less resolution, which is four times by area of the image in pixels. For example, when rendering resolution is 800 by 450 pixels, the next step of undersampling is 400 by 225, the next one is 200 by 113 and so on. It is worth noting that IM can use both the undersampling and supersampling. That is, IM can be calculated on less and on larger than the actual rendering resolution, in an even number of times, resolutions.

Each phase of the GI rendering called pass. The pass, which determines the important areas of the scene, called `Prepass`. The progress of passes calculation, their total number, and what prepass is calculated at the moment, can be observed in the `Rendering` window, which pops up after starting the rendering.

Let us see, how IM calculation looks like on the example of four prepasses.

In this example, the maximum resolution of IM rendering is a resolution of 800 by 450, equal to the resolution of the rendering of the final image. To fully identify important areas, first used three undersampled prepasses at lower resolutions: 100 by 56 in the first prepass, 200 by 113 in the second prepass, and 400 by 225 in the third. Together with the final prepass, there are total four IM prepasses.

Look at the first prepass. You may notice that it had not allocated any areas, the entire image calculated equally with the same accuracy as the BF algorithm does. But completely different picture can be seen already at the third and especially the last fourth prepass. It is clearly apparent how the IM algorithm highlighted the important details of the scene, strewed them with GI samples, and significantly thinned out flat not detailed surfaces. They are unimportant the parts, such as walls planes, the flat face of the cube, etc. They have only a few points that will later be simply interpolated between them by IM algorithm, filling the empty zones. Also, we can immediately see that the size of samples with respect to the entire image at different prepasses is different, because the higher the IM rendering resolution, the lower the value of a single sample, and so more detail and more accurate irradiance map is.

It is not hard to guess that GI map, calculated with IM even on the full final resolution without advance prepasses, so without calculating the important areas will be just as tough and not adaptable, as in the case of GI rendering using the BF algorithm. The time to calculate it will certainly be nearly as long, as in the case of BF.

This image shows the `Irradiance map`, calculated by one prepass right at the final resolution. When looking at it, it seems that there are no samples at all. However, it is just the opposite. All that is seen in this picture, these are all samples, very tight-studded the each pixel on final resolution. Thus, the irradiance map is not concentrated in some important areas; it completely covers all scene objects visible from the camera. Obtaining such a dense map entails such as many calculations. In particular, all four prepasses in the first case were calculated in 5 minutes, while calculation of only one pass in the second case took 50 minutes of computing time. The difference is more than obvious. Make no mistake that in the second case, the quality of the final image will be substantially better than in the first, because of richer map. The fact is that the unimportant areas of the scene represent mostly flat surface of one color; the color of GI there, is homogeneous and without details in both cases. However, important areas of the scene, in fact, that were calculated with and without adaptation, are equally detailed. That is why there is no point in spending ten times more computing resources on rendering homogeneous flat surfaces to get essentially the same result. We believe that the scale of time saving, when calculating the with IM, comparing to the time of calculation with BF, is quite obvious.

When the map of important points that contain the GI color information, has been calculated, the interpolation of missing GI points is starting. Then on rendering, in each point, as in the case of BF, performed calculation of a fixed number of secondary light rays over the hemisphere, as described in the previous tutorial.

The parameters located at the `V-Ray:: Irradiance map` rollout are responsible for the areas that the IM algorithm will consider important, the number of secondary rays that IM will generates for calculation of each IM cloud point, and the resolution at which the scene details need to be probed.

`Current preset` is just a quick set of preset values for the main parameters of IM. Dropdown list with these sets is in the `Built-in presets` zone. The purpose of each of them can be easily understood by their names, they speak for themselves: Very low, Low, Medium, Medium animation, High, High animation, Very high. However, the greatest interest to us is the Custom option. As its name implies, this value allows us to manually configure IM. Feature of `Current preset` option is that if you select one of the presets, and then select Custom, then numeric fields of IM parameters will keep the values of the last preset. By default settings, IM is preset to 8High, it is this preset we should choose for the start and then change the basic parameters of the IM, selecting the Custom.

Next, the `Basic parameters` zone options come. These are obviously the basic IM parameters.

`Min rate` is a value that determines the resolution of the first prepass of GI.

`Max rate` is a value that determines the final resolution of rendering GI or simply the resolution of the last prepass.

As we already know, the IM algorithm with a few GI calculation steps selects the most important and detailed areas. If you look at the examples above, in the upper right corner you will find the value of rate, which determines the resolution of current prepass in rendering IM. Rate value 0 (zero) means that the calculation of GI will be in a resolution equal to the resolution of the final rendering. Rate value equal to -1 means that the calculation of GI will be in a twice lower resolution than the resolution of the final image. Rate value equal to -2 means that the calculation of GI will be in a twice lower resolution than the resolution of -1 rate, which means four times less than the final image resolution. By analogy, the rate value equal to 1 would mean that the calculation of GI will be doubled comparing to resolution than the resolution of the final image, etc.

The `Adaptive subdivision`, anti-aliasing algorithm, uses a similar concept of undersampling and supersampling, this was discussed in detail in the first tutorial of this series.

The following examples illustrate this:

On the first image, where the IM has been calculated on the final resolution of the rendering there is a little more clear and dense shade under the sphere than on the second image, as well as more precise and sharp shadow at the bottom of the cube, especially seen in its left corner. This is because in the first case, IM has a lot of small details, while the latter are interpolated from a smaller IM resolution. However, the render time of IM in the first case (`Max rate:` 0) by more than 5 times greater than when the last prepass was calculated at 8 times lower resolution (`Max rate:` -3). Five minutes and three seconds against fifty-seven seconds. At higher resolution and more complex scene, the time difference calculation IM will be even greater. At the same time, at high resolutions such as 2500 – 3500 pixels by a side, which is by the way should be used in the final rendering, this difference will be less noticeable due to the overall resolution increase. In addition, this slight and pale blur of details in a few minutes elementary eliminated in 2d graphics editor. In practice, the values of the `Min rate:` -5 and `Max rate:` -3 is sufficient for the good photo-realistic rendering, and these values should be set in start V-Ray configuration.

Parameter `HSph. subdivs:` (in a more expanded form HemiSphere Subdivisions) is the number of rays of GI, reflected from a point on the surface of the object. This parameter determines the amount of diffuse light rays taken of each secondary point IM, as mentioned earlier, in the form of a hemisphere. That is a complete analog parameter to a `Subdivs` in BF algorithm. In most cases, the `HSph. subdivs:` value, equal to 80 is enough and that it should be set for universal V-Ray configuration.

`Interp. Samples:` is the parameter that determines the quality of interpolation of the IM. Remember the examples with IM samples, where the samples were marked with light dots, and missing areas with gray color. `Interp. Samples:` determines the quality of interpolation of not important gray areas with missing information, from the white-dotted important areas. The higher the value of `Interp. Samples:`, the higher the interpolation, resulting more blurred GI, while at low values of `Interp. Samples:` GI map is less "soapy", but more noisy with lots of artifacts. Default value of 20 samples is enough, and this value should not be changed.

As we already know, IM with help of prepasses feels for to the scene to identify its most detailed parts. IM does so, based on previous prepasses information, and it is guided by three main critical in terms of details properties. This is color, difference between the normals, and the relative position of objects. In the IM, these properties are presented with `Clr thresh:`, `Nrm thresh` and `Dist thresh` parameters respectively.

`Clr thresh:` determines the sensitivity threshold of the algorithm IM to the colors of the scene. The higher the threshold, the less color changes on the objects of the scene will be considered as important areas and the easier will be the calculation of IM. Lowering the sensitivity threshold of the algorithm will make IM more sensitive to color changes in the scene and would create more detailed IM, and so the better pictures. `Clr thresh:` parameter value equal to 0.3 is quite acceptable to create an acceptable IM and in universal V-Ray settings we should use it.

`Nrm thresh:` defines the sensitivity threshold of IM algorithm to the scene geometry, in particular to the intensity of change of the object’s normals in it. The lower the threshold, the more geometric details on the objects of the scene will be considered as an important area, respectively, higher quality will be the final image. The parameter `Nrm thresh:` equal to 0.1 is enough for a well-detailed IM and it should be used in universal V-Ray settings.

`Dist thresh:` defines the sensitivity threshold of the IM algorithm to neighboring geometric surfaces in the scene. The higher the threshold, the farther each to other surfaces will be considered as an important area and better will be the final image. Looking at the showed above example, you can easily understand the difference between parameter `Dist thresh:` and parameter `Nrm thresh:`. If from `Nrm thresh:` in this scene will depend the density of the IM in the corners of the room, then`Dist thresh:` will determine the detail of IM in the zone of the close location of the sphere and cube to each other. It should be noted that, when the threshold`Dist thresh:` is lowered, it will take into account only the smaller distance between the surfaces of objects, thereby reducing the density of the samples of IM, and hence the quality of the final image. Pay attention that it is in contrast to the `Clr thresh:` and `Nrm thresh:`, where the decrease of threshold improves image quality. The parameter`Dist thresh:` of 0.1 is enough to create a good IM and we should use it in universal V-ray settings.

The last parameter, located in the zone of Basic parameters, it is inactive `Interp. frames:`. It is responsible for a number of irradiance maps, calculated for different frames of animation in the mode of Animation (prepass), which V-Ray will use to render the current frame in Animation (rendering) mode. It is in the last case, this option will be active and available for change. However, these are very specific modes of IM, which will be described in the tutorial on rendering various types of animation in the V-Ray. By default, in the universal V-Ray settings this option may be left unchanged.

In `Options` zone of the `V-Ray:: Irradiance map` rollout can be enabled options, which are responsible for IM rendering in the frame buffer. These options enabling let us to observe clearly the IM prepasses calculation, to show direct light with the GI on the prepasses rendering and to watch the location of samples on the IM. For these functions response parameters `Show calc phase`, `Show direct light` and the `Show samples`, respectively. These are all test functions that do not affect the IM rendering, and in the universal starting V-Ray settings they should not be activated.

The next area of IM parameters is the `Detail enhancement`.

As we know, the main highlight of IM is the calculation of important details of scenes with prepasses at lower resolutions. Option `Detail enhancement` allows us to create a hybrid between an adaptive, but making a little fuzzy samples map IM algorithm and a rough, but precise in details, Brute Force.

When the function `Detail enhancement` is activated, IM, as well as before, uses prepasses to calculate the details of the scene. However, at the last calculation pass, when the final information on the detail in the scene is obtained, the algorithm `Detail enhancement` comes into play. The principle of `Detail enhancement` work is that GI samples of the most important areas are calculated by the algorithm Brute Force at full resolution of the final rendering, without undersampling. All other areas, as in the normal mode of IM, are calculated by interpolation.

The algorithm of `Detail enhancement` for the determining of what samples in important areas should be calculated, based on the principle of the algorithm similar to the Ambient occlusion (AO), but, in contrast to AO, `Detail enhancement` algorithm takes into account the direction of light.

It is worth to note that when `Detail enhancement` is activated, IM algorithm is used only to determine the detail of the scene, and direct rendering of important details lies on the BF component of `Detail enhancement`. Knowing this, if the option *Detail enhancement *is active, we can lower all the parameters of the IM, except Interp. samples. Parameter Interp. samples can even be set to larger values.

Algorithm is activated by setting the tick in the checkbox `On`. Then become active settings such as `Scale`, `Radius` and `Subdivs mult.`.

`Scale` defines the units of measurement of the following Radius parameter.

`Radius` is the value of the hemisphere radius, which defines the area in which the BF will calculate the GI samples from the reference point. Location of reference points of BF, as mentioned above, is determined at the stage of calculations of detail of the scene with prepasses.

`Subdivs mult.` is in fact a complete analog of `Subdivs` parameter of the BF algorithm, which determines the number of diffuse rays. It is set as a percentage of the current `HSph. subdivs:` value.

To better understand what is the radius of the hemisphere, and what hemisphere point we are talking about, we should be closer acquainted with the concept of AO. Explanation of this concept is beyond the subject of this tutorial, but it will be discussed in detail in separate article on AO and, in particular, areas of application of the parametric VRayDirt map. In any case, `Detail enhancement` is a specific option, which greatly reduces the adaptability of IM and significantly increases the time of GI rendering. That is why it should not be activated unnecessarily and, of course, in the universal V-Ray renderer settings also.

Next in the IM settings is a zone of Advanced Options.

`Interpolation type` is drop down list that allows us to choose the method of interpolation if IM samples, i.e., the algorithm that fills the missing areas in the IM, getting the absent sample data from already computed ones. This list contains four methods, they are Weighted average (good / robust), Least squares fit (good / smooth), Delone triangulation (good / exact), and Least squares with Voronoi weights. Technically, they have different mathematical principles to calculate the result. It is absolutely no need to delve into how they work. End user need only to look at the clues given in parenthesis at the end of each of them, and immediately become clear about their features. Optimal interpolation method is the default Least squares fit (good / smooth). That is it worth using in the starting V-Ray configuration.

`Sample lookup` is a drop-down list, allowing us to select a method that determines which of the calculated IM samples will take part in the interpolation of missing samples in the surrounding areas. There are four sample selection methods, they are Quad-balanced (good), Nearest (draft), Overlapping (very good / fast) and Density-based (best). These also are algorithms, each with its own mathematical peculiarities in the methods of selecting the desired samples, in which it is not necessary to delve without special need. Similarly to the Interpolation type methods, the tips in parenthesis next to their name perfectly explain their features. By default, the best method of Density-based (best) is set and exactly it we may use in universal V-Ray settings.

`Calc. pass interpolation samples` - a value that specifies the number of computed samples that will guide the IM interpolation algorithm during the last calculation pass. Nominally assigned value of 10 samples is enough to get good results. It should be used in universal settings of V-Ray.

`Multipass` is a feature that allows the current IM prepass to be able to use absolutely all available samples, calculated for the current particular moment. That is to say, the samples from previous lower resolution prepass, and samples that are already computed in the current own prepass.

Irradiance map is computed as the final render, in many threads to fully utilize the potential of modern computing systems, which are often multi-threaded through multiprocessing and multi-core. Initially, when calculating IM by multithreaded system, every piece of IM is calculated by a separate thread, independently each from other. The data for this calculation is taken only from the previous prepasses. Because of this, it turns out that each piece of calculation of IM, without information about the surrounding portions gives inconsistent with them results. On the calculated in this manner IM become evident the boundaries of those portions in the form of lattice.

Look closely at the picture. There are clearly visible linear boundaries of IM calculation per-thread portions. For example, this effect is very noticeable on the sphere and on the wall to the right, on the ceiling above the cube.

Enabling of `Multipass` function allows the IM algorithm to use information about the current prepass samples. That is, when rendering each portion, it allows the IM algorithm to use information about the adjacent calculated portions, giving a consistent smooth result. Thus, in practice, `Multipass` function allows to smooth the boundary between the IM calculation portions, giving homogeneous IM, without any visible artifacts in the form of a lattice. In the universal starting V-Ray configuration, this function should always be kept active.

`Randomize samples` is a feature that allows to generate samples of IM in a random order, making IM more realistic. Nominally, the IM algorithm selects the samples on scene objects with regular intervals, resembling a grid, even if the considered above option `Multipass` is enabled. This effect clearly can be seen in the image below.

To resolve this regularity, which betrays the computer origin of the image, and prejudices photorealistic renderings, function `Randomize samples` in universal V-Ray settings we surely must keep activated.

`Check sample visibility` is a feature that allows us to interpolate the samples of IM, only being in sight of each other. Very often, due to the low density of IM, in the process of interpolation of missing samples, the IM algorithm takes the neighboring samples that fall within the zone of sampling for a given point, even though they may be located outside the visible area relatively to each other in the scene. For example, we have a bookcase with a thin wooden shelf, lying close to the rear of this bookcase. On the top of the shelf is a light and it illuminates shelf’s upper part. Under the shelf, direct rays of light in no way can fall. Nevertheless, beneath a shelf at the rear can easily appear bright spots, despite the fact that they simply cannot be there. This happening because the IM algorithm to interpolate the missing samples in the area below the shelf, takes adjacent samples from the upper part of the shelf, without considering actual geometry. To avoid this, the IM interpolation algorithm is necessary to know that we want to check what samples are in the zone of direct mutual visibility, and what are not. Of course, such a check would require additional computational resources.

It is better to look at `Check sample visibility` example from V-Ray Help, it perfectly illustrates how this function works.

This is a very useful feature, however, in most scenes, the above-described artifacts are absent, and there is absolutely no need to always verify visibility of samples, needlessly wasting computing resources. In the universal starting configuration of V-Ray, feature `Check sample visibility` should be disabled.

In areas `Mode` and `On render end` we can set the IM working mode, needed for animation rendering. We can specify a folder and name on the hard drive, under which the computed IM can be saved. As mentioned earlier, to the animation in V-Ray a separate tutorial will be devoted, in which these options will be discussed. In starting universal V-Ray settings these options should be left untouched as they are by default.

## Conclusion

In this tutorial, we were introduced in detail to important aspects of two GI algorithms, they are straightforward and exact `Brute Force GI` and biased approximate `Irradiance Map`. And we chose to use adaptive `Irradiance Map` as `Primary bounces` `GI engine`, because it allows us to get acceptable results at lower computational costs, ie much faster. In particular, we carefully researched all the details, aspects and settings of IM and were able to clearly see the impact of each important settings on numerous examples.

See you in the next chapters of this tutorials series!

voron81
Feb 12, 2011
Thanks! Very informative!
Alex
Feb 13, 2011
Thank you for this analysis! This is a very useful info! Just wanted to ask a question! You didn't say anything about saving the IM to the drive for future use. The fact that this can be done to reduce waiting times is interesting in itself. And I've heard 'the myth' that if you calculate and save a low-resolution IM, then you can use it to render the final image at a higher resolution. Based on what you say here, this can be done. Am I right?
RenderStuff
Feb 13, 2011
Hello Alex.

Of course, the IM can be stored on the drive and then loaded to calculate the final image with a resolution higher than the one on which the IM was previously calculated. However, the 'Max rate' ​​property is actually controls the maximum resolution at which IM will be calculated. Therefore, there is no advantage to pre-save the IM and then load it from drive. You just waste time on saving / loading operations. So, just set the desired value of 'Max rate' to set the final IM resolution as you need, and you will literally get the final image rendered at a higher resolution than IM. So this is just a myth, there will be no benefits from this 'technique'. The settings for saving and loading IM have a different purpose, mainly for rendering animation (but not only) and this is a topic for a separate tutorial. So, in order not to complicate or deviate from the flow of this tutorial, we simply did not mention it.

Alex
Feb 13, 2011
Well, yes, I agree ... thank you! But I can add IM with IM? Right? This way, you can calculate the IM from one camera and then use the IM saved earlier (from the previous camera) when calculating the same scene from another camera. It looks very interesting. I think it can speed up rendering... although maybe stupidity...
Alex
Feb 13, 2011
We look forward to the next chapters!
RenderStuff
Feb 14, 2011
Actually it is very clever professional trick you are talking about.

You can even render IM from one camera and then later use it from another camera to calculate samples only in areas where there are no samples yet, thus saving calculation time.

There is even a technique where you place a Box camera inside the scene (the center of the room), calculate the 360-degree Irradiance map, and then later use it to render the scene from different cameras.

As I said, these are very professional tricks, and for those who are just beginning their journey into the world of photorealistic V-Ray visualization, these tricks will be too difficult to understand. But again, you are thinking in the right direction!

Mar 2, 2011
Hi, thanks for this analysis of the settings, I have long lacked an understanding of the basics!
Iliya
Apr 11, 2011
Great article! I am really looking forward to the tutorial on animation from you!!!
ASRockus
Aug 6, 2011
Dear RenderStuff, I decided to experiment with V-Ray settings your recommended. I created a scene similar to the scene from tutorial, with VrayLight in a window. But I have a strange behavior of light. With global lighting, the result is pretty similar to what you have, but noisy. When there is only direct light, the render looks just different. It's very dark. I would like to hear a suggestions, what's wrong? With respect!
RenderStuff
Aug 6, 2011
Hello,

Your scene looks almost the same. There are not so many differences. You have a slightly larger VRayLight plane, as well as a cube almost the same height as the sphere. Because of this, part of the sphere is illuminated by direct light falling from above. Decrease the height of the light or increase the height of the cube, and you get an image very similar to the one in the tutorial.

In terms of noise, your VRayLight has only 8 Subdivs. This is a low level for smooth shadows. This is not because of GI. In our scene, to rule out a similar problem, the Subdivs value is 120. You can set something smaller. About 30-40 should be fine, and the noise in the shadows will gone.

ASRockus
Aug 6, 2011
As you advised, I raised the VRayLight subdivs to 30, increased the cube size, turn on GI. The noise became weaker, but did not disappear completely. At the same time, I have ugly black dirt behind the cube. In your example, you have a sphere in soft darkness (so to speak), and I have a black black spot. Here's what I have with GI and without.
RenderStuff
Aug 6, 2011
Continue to increase VRayLight subdivs until the noise is completely gone. Also, to be exact, you have a Box, not a ChamferBox like we have. And we have a slightly different ChamferBox configuration. Geometry also plays a role in illumination of the scene.

One more. Looks like you have a gamma problem. Please refer to our complete Gamma 2.2 manual for 3ds Max & V-Ray and make sure you have set the correct values.

ASRockus
Aug 6, 2011
Thanks RenderStuff for the help. Much has become more understandable, much has become clearer. May I ask you even more questions, if any, during my experiments, so to speak? Thanks again.
RenderStuff
Aug 6, 2011
Of course, ASRockus, we will be happy to help!
Fco3d
Aug 30, 2011
Excellent explanation I been looking for something like this long time, congrats very helpful.
oumhani
Nov 20, 2011
great tutorial, so easy to understand complex concepts, thanks
Ant
Feb 22, 2012
Great tutorials but you were very quick to discard Brute Force as a GI option

When it used in the right hands, and with enough experience and understanding of Vray's render settings, Brute Force provides superior GI calculations resulting in highest quality. You are correct that it can be time consuming, but I feel that this (IM complexity) may scare away newcomers and could prevent them from ever achieving a Vray's ultimate results.

Aside from that, your tutorials is very informative help to the CG community alot.

Mar 22, 2012
Great tutorials, I'm new to v-ray and these are by far the best tutorials i have seen regarding v-ray initial setups.thanks
Ioan Alex
Jan 25, 2013
Thx for explaining all options in details. Great tutorial. Thx!!
Dec 28, 2013
Hi, this is a great tutorial! I have a question. What is the right balance between an IM filled with points (samples) and one that has fewer samples? When do I have to stop changing my IM settings? Is there a rule for this? How to determine if this is a good IM samples density or not yet? Thanks.
Maks (RenderStuff)
Dec 30, 2013
Theoretically, the correct balance of points is when there are many samples on small details of geometry, and few samples on flat one-color surfaces. This way, you won't get blotchy rendering, but it will be relatively quick because no time is wasted on surfaces without details. Theoretically, the best way to achieve this is to use seferal passes, where the detailed and flat areas will be defined more accurately with each pass. But more pases - meant more time. So, three or four passes, it's somewhere in balance.

In practice, however, we do not recommend looking at IM at all if you do not have any mysterious artifacts. The observing of IM samples can really help solve such problems. But the most convenient way is to view the visualization results directly and increase the resolution of the IM, if you do not like the look of the final rendering. The final render is a goal, not an IM. After all, Irradiance Map is only one of components of final visualization. Therefore, it does not matter what the actual samples of IM look like if the final render looks great and vice versa. Focus only on the photorealism of the final render, and if there are no artifacts - then everything is fine.

Olivié C
Jun 14, 2014
Thank you for this great tutorial. 2 notes : > your explanation of "Interp. Samples" is not in line with the V-Ray online manual : it's not about the "quality" of the interpolation but rather about the "quantity" (number of IM samples interpolated). You say "Default value of 20 samples is enough, and this value should not be changed." well you actually need to increase this when you use high IM quality (say Max rate = 0) in order to avoid artefacts (since you need to interpolate more samples to smooth the highly sampled GI). Increasing "Interp. Samples" can actually be necessary in such cases for interior rendering. > "Min rate -5 and Max rate -3 is sufficient for the good photo-realistic rendering" well this sounds a bit optimistic and a good advice for preview, but it's still ok to render the final image with Max rate -1, or 0 if usefull. Thanks again for your tutorial !
Anton (RenderStuff)
Sep 20, 2014
Hi Olivié C!

I appreciate your attention to detail. Further, I will answer each note separately.

Interp. samples. 20
You're kind of right, but let's just look at what the official manual says:
The number of GI samples that is used to interpolate the indirect illumination at a given point. Larger values tend to blur the detail in GI, although the result is smoother. Smaller values produce results with more detail, but may produce blotchiness if low Subdivs are used.

Color interpolation is always about reduction of a certain amount of data to one value. In our case, this is the calculation of the color of one IM point, by reducing a certain number of adjacent points colors. I say reducing because I have no information about what exactly is happening, but for simplicity let's assume that this is just a calculation of the average value, ie (sample1 + sample2 + ... + sampleN) / N = NewSample.

If, for example, Interp. samples = 20, this probably means that to calculate one particular NewSample, 20 adjacent samples will be taken. Of course, when you mix other colors into one to get a new value, the new value will not be clear or detailed, it will be blurred, artificially reproduced. The more samples taken, the more blurred the result. For example, we have two cubes next to each other, one green, one red and gray gap between them. When the color of the gap is calculated, the green and red colors of the cubes will be mixed with the gray color of the gap. As a result, instead of a gray gap, it will be a dull yellowish color between the cubes. So, instead of sharp devision, we will get something average between.

On the other hand, if you reduce the Interp. samples value, and if there are not enough samples on the gap, it may happen that the NewSample color will be zero or absent. And on the visualization it will look like a dark spot or blotch.

And here we are at the point where it is more of a philosophy than a strict term. Which is better, a blurry but not blotchy render or a sharp and detailed render but with lots of blotches on most small details? We prefer to think that the first case is better, despite the blurriness, because blurriness is not so critical for GI. But muddy, blotchy artifacts are definitely not what you expect from a realistic visualization. That's why we wrote that Interp. samples it is about the quality of interpolation, because it so in a sense. However, if you continue to increase Interp. samples, you will get 'flying' objects because of blurry GI underneath. And that's why, we said that value of 20 is optimal. It is prevent lot of blotches but still not cause redundant blurriness. So I can't agree with you that you need to increase Interp. samples. more than 20, especially whan you have a good quality Irradiance Map. In this case, I even suggest doing the opposite, revealing more details without worrying about 'dirt' in the corners. It makes no sense to increase the blurring of the IM whan there are already enough samples in it.

Max rate -3
I agree with you again that in some cases -3 is not enough and you can increase it up to, say, -1. But 0, to be honest, it contradicts the philosophy of adaptability or approximation. As far as I understand, the approach of the Irradiation map is based on two pillars. Probing, is when IM begins to determine where more samples are needed, starting with the lowest resolution (Min rate), to calculate as few samples as possible at the final IM resolution (Max rate). And, lets call it 'undersampling', when the maximum (final) resolution of the IM is lower than the actual resolution of the final render. Because IM is no better than Brute force, it is actually worse, less precise, because it is a shortcut technique, that reduces rendering time by sacrificing detail in less important areas, and renders GI map at a lower resolution. Max rate 0, means IM rendering at full resolution of a final render. In this case, you not exclude probing, but completely eliminate undersampling. Why use blurred approximate IM if you don't utilize its main advantage over precise exact BF? It doesn't make sense. The difference, in terms of rendering time, between IM on full resolution vs BF - will be insignificant, but the loss of details will be meaningful. I would say that if you have a situation where you need to to render IM at full res, there is definitely something wrong with the scene setup. But ok, let's assume it is just super complicated scene with a high density of small details, maybe you should consider to use BF instead? It may be a little noisy, but much more precise.

In any case, it is very cool that you comment on the essence of the content and thoughtfully read what is written here. I am very grateful to you for the notes, they help a lot to improve the quality of the content and perhaps our discussion will help to somwane else to understand what's what.

Of course, you are free to use your own approach, including Max rate 0, but, if you can afford (waiting time and computation power) rendering IM at full res, at least try to compare it to a much simpler BF. It has way less settings than IM, and it is more convenient and predictable in use.

Cheers!
